c版本参数捕获代码说明¶
wings参数捕获功能主要是在运行时获取函数的参数值,全局变量值以及返回值的信息
参数捕获代码的命名规则¶
wings的参数捕获代码存储在paramcaputrecode文件夹中。其中命名规则同驱动格式一样,将所有的driver替换为param即可。
参数捕获代码的示例¶
如下所示,针对函数coordinate_destroy中,会自动生成捕获参数、全局变量以及返回值的信息。
#ifndef _PARAMCAPTURE_WINGS_C_DEMO_COORDINATES_H_
#define _PARAMCAPTURE_WINGS_C_DEMO_COORDINATES_H_
#include "ParamCapture.h"
#include "ParamCapture_structorunion.h"
void ReturnCapture_coordinate_create(coordinate_s returnType);
void ParamCapture_coordinate_destroy(location *loc, size_t length, char *ch);
void GlobalCapture_coordinate_destroy(int count);
void ReturnCapture_coordinate_destroy(int returnType);
void ParamCapture_func_point(double param1, int param2);
void ReturnCapture_func_point(void returnType);
#endif // WINGS_C_DEMO_COORDINATES
下图将展示捕获全局变量的自动生成代码。
